Material takeoffs for framing depend on stud spacing, wall length, and layers of top/bottom plates.

This tool gives fast counts for straight runs before you subtract doors and windows manually.

Always add waste factor and confirm with local code (e.g., high-wind spacing).

16 in on center is standard in many US builds; 24 in OC appears in some engineered designs.

Metric projects often use 400 mm or 600 mm modules—pick the unit that matches your drawings.

Measure along the plate line where studs will sit—ignore temporary bracing offsets.

For angled walls, measure the longer developed length along the framing path.

Convert all measurements to the same unit before dividing.

Snap lines on the deck to verify spacing before standing walls.

Start from studs = floor(length ÷ spacing) + 1 for a simple open run.

studs ≈ floor(L / OC) + 1   (open run, no openings)

Add kings, jacks, and cripples around each opening after the base count.

Corners often require overlapping studs or California corners—local detail sheets win.

Double top plates spread loads; single bottom plates sit on the anchor bolt line.

Multiply plate linear feet by layers, then divide by stock length to estimate board counts.

Each wide opening consumes studs for king/jack pairs and sometimes cripples below sill height.

Intersections and T-walls need stud packs per your engineer’s detail.

Subtract large garage doors from rough counts manually.

Add 5–10% waste for cuts and culls on lumber orders.

2×4 and 2×6 are common in US residential; commercial may use steel studs with different math.

Actual vs nominal thickness affects insulation depth but not on-center stud count.

Quick glossary for adjacent framing members:

Cripple stud

Short stud above or below an opening, cut to fill partial bays.

Jack stud

Supports the header; runs full height from plate to header bottom.

King stud

Continuous stud alongside the opening that ties plates to the header assembly.

Header

Beam across the opening; depth grows with span and loads.

Sill / saddle

Bottom framing member of a window opening; often pairs with cripples below.
